High Pressure 42Mpa Axial Piston Pump For Farm Equipment

Shandong Highland Hydraulic Seiko Co., Ltd.
Contact Now

High Pressure 42Mpa Axial Piston Pump For Farm Equipment

  • 1
  • 2
  • 3

Brand Name : HIGHLAND

Model Number : HPV110

Certification : PATENT CERTIFICATE

Place of Origin : CHINA DEZHOU

MOQ : 5 sest

Price : USD1200-1500/set

Payment Terms : T/T, Western Union

Supply Ability : 500 sets per month

Delivery Time : 5-8 working days

Packaging Details : Plywood case

Max.displacemen : 110 ml/r displacement

Model : HPV110 model

Drive mode : Hydraulic drive

Medium : Hydraulic oil

Function : Hydraulic system components

Structure : Axial piston

Warranty : 1 Year

Material : Cast iron

Package : Plywood case

Product name : High Pressure 42Mpa Axial Piston Pump for Farm Equipment

Contact Now

High Pressure 42Mpa Axial Piston Pump for Farm Equipment

Hydraulic axial variable displacement piston pumps basic information and selection:

In the world of agricultural machinery, the hydraulic axial variable displacement piston pump assumes a crucial position. Its primary role is to deliver a precisely controlled oil flow at specific pressures, making it the linchpin of agricultural hydraulic setups. The importance of selecting the right hydraulic pump cannot be emphasized enough, as it directly influences energy efficiency, overall agricultural equipment performance, noise levels, and system reliability. The selection process follows a fundamental principle: first, calculate the pump's displacement based on the operating conditions of the farm machinery, power requirements, and performance expectations. Subsequently, choose the appropriate pump model and specifications based on the system's pressure and flow demands.

Customers should determine the following requirements before ordering hydraulic pumps:

1. Hydraulic axial piston pump and motor displacements.

2. Rotation direction of hydraulic axial piston pump.

3. Hydraulic shaft type and shaft teeth quantity.

4. Control mode.

5. Usage of hydraulic axial variable displacement piston pump motor.

6. Send label or pictures as more as possible

High Pressure 42Mpa Axial Piston Pump For Farm Equipment

42Mpa High Pressure Hydraulic piston pumps technical specification:

HPV Series Technical parameter

HPV hydraulic pump and HMF hydraulic motor series

30

50

70

90

110

130

Displacement

Max displacement

ml/r

30

50

70

90

110

130

Speed

Max continuous working speed
(Full load condition)

r/min

3500

3500

3200

3200

2900

2900

Rated speed

r/min

2500

Min continuous working speed

r/min

500

Pressure

Rated working pressure

Mpa

35

Max working pressure (transient)

Mpa

42

Continuous working pressure

Mpa

30

Allowable shell pressure (Absolute)

Mpa

Constant0.25, Peak value0.5

Torque

Continuous output torque
(Under continuous working pressure)

Nm

162.3

252.3

342.6

432.9

535.3

632.4

Max output torque

Nm

227

353

480

606

749

885

Power

Continuous output power

KW

45

79

107

139

149

176

Max power

KW

62

95

114

150

173

205

Temperature

Allowable shell temperature

80

Max working temperature of oil tank

70

weight

HPV series hydraulic pump

hydraulic oil emptying

kg

45

46

63

64

82

88

HPV series hydraulic motor

hydraulic oil emptying

kg

30

30

36

36

36

38

High Pressure 42Mpa Axial Piston Pump For Farm Equipment

Hydraulic axial piston pumps usage:

Hydraulic axial piston pumps are widely used in high-pressure, high-flow, high-power systems and occasions where the flow needs to be adjusted, such as agricultural machinery, tractor and combine harvester, construction machinery, mining and metallurgical machinery, and ships. It can play an important role.

Notices:

Be vigilant in preventing cavitation, a condition where air bubbles form in the hydraulic fluid due to low inlet pressure. This can lead to damage within the pump and other components. Maintain adequate inlet pressure and utilize air removal devices when necessary to minimize the risk of cavitation.

Ensure that all personnel operating hydraulic systems, including the piston pump, receive comprehensive training. This should cover system operation, maintenance procedures, and safety precautions. Well-informed operators are more likely to use the equipment correctly, leading to longer equipment lifespan and safer operation. Regularly review safety protocols and provide refresher training as needed.

FAQ of hydraulic axial piston pumps:

Q1: Could I have a sample order?

A: Yes, we welcome sample order to test and check quality.

Q2: How do you ship the goods and how long does it take to arrive?

A: Ship by air express, it takes 3-5 days to arrive. Airline and sea shipping also optional.

Q3: Do you offer guarantee for the products?

A: Each motor or pump should be tested before shipping, test report can be sent if requested.

Warranty 12 months after shipment for complete assembly.

Q4: What are the payment terms?

A: Full order: 30% as deposit, balance before shipment.

Small order/sample order: Full advance payment.

Q5: Are you manufacturer?

We are a manufacturer with own plant manufacturing hydraulic piston pumps, 20 years experiences in hydraulic industry for oversea and domestic markets. Welcome to visit our factory in Dezhou city Shandong province.
